The WJS 100 features all the advanced process control technology you have grown to expect from PACE but now with
nearly twice the maximum power output to make easy work of your most challenging, high-thermal-mass or high-volumesoldering applications.
Integral to the WJS 100 solution is a special range of gold-end tip-heater cartridges* uniquely engineered to deliver maximum
heat through-put to the work and increase productivity while allowing you to solder at safer, lower temperatures—even withlead-free solder.
The WJS 100 is fully programmable, loaded with features, and incorporates PACE’s exclusive IntelliHeat® Control Technology.
The WJS 100 comes standard with a special anniversary edition of PACE’s renowned TD-100 Thermo-Drive® Handpiece,considered by many to be the most comfortable soldering handle available.
• IntelliHeat® Control Technology.
• Fully programmable, digital processor, LED display
and keypad.
• Password lockout
• Temp Setback and Auto-Off helps to maximize tip
life and saves on power costs.
• Defi nable Operating Temperature Range via “Hi”
and “Lo” Setting.
• Nearly twice the maximum power output increases
productivity at safer, lower temperatures—even on
the heaviest loads.
