captop EP500内螺纹塑料盖 上海厂家现货 价格实惠 免费发样
可纬化工贸易（上海）有限公司
上海市江宁路1165号圣天地706室
产品属性
图文详情
品牌推荐
'
captop EP500内螺纹塑料盖买家必读：
由于规格尺寸不一，价格也相差较大，请买家在拍下前务必联系卖家，由卖家推荐适合的产品及型号并报价。致电021－5252 0303是最快捷的方式。
可纬化工是创建于2006年的外商独资企业，分为包装、机械、精细化学品、塑料制品四个事业部，我司的产品及服务已得到几百家企业的认可，包括：德国博世、中化集团、美国海沃氏家具、徐工集团、意大利沃而福等。
更多塑料密封盖信息尽在可纬化工(Covalentsc)
- 超过6000种产品，一站式采购，便于你的供应商管理
- 所有产品采用精密模具和全新料加工，提升你的产品品质
- 全部现货，实现客户零库存，最大限度增加你的现金流
- 免费样品，试样合适再确定是否采购，降低你的采购风险
- 所有产品均可提供材质报告及环保认证
- HDPE 螺纹盖减少潜在的剪应力
- 氯丁橡胶密封垫片防止液体泄露
- 建议手工旋紧
- 外六角设计可用扳手或套筒低扭力装配或拆除
公制螺纹塑料密封盖
| 零件编号 | D (mm) | h (mm) | H (mm) | SW1 (mm) | SW2 (mm) | 配用螺纹尺寸 | 标准包装数量 | |
| 467033 | 12.0 | 11.0 | 13.0 | 10.0 | 11.0 | M8 x 1 | 500 | |
| 467034 | 14.2 | 11.0 | 13.0 | 12.0 | 13.2 | M10 x 1 | 500 | |
| 467035 | 16.5 | 11.0 | 13.0 | 14.0 | 15.4 | M12 x 1 | 500 | |
| 467036 | 16.5 | 13.0 | 15.0 | 14.0 | 15.4 | M12 x 1.5 | 500 | |
| 467037 | 18.5 | 13.0 | 15.0 | 16.0 | 17.5 | M14 x 1.5 | 500 | |
| 467038 | 21.0 | 13.0 | 15.0 | 18.0 | 19.7 | M16 x 1.5 | 500 | |
| 467039 | 23.0 | 13.0 | 15.0 | 20.0 | 21.9 | M18 x 1.5 | 500 | |
| 467040 | 25.0 | 13.0 | 15.0 | 22.0 | 24.1 | M20 x 1.5 | 500 | |
| 467041 | 27.5 | 13.0 | 15.0 | 24.0 | 26.3 | M22 x 1.5 | 250 | |
| 467042 | 30.0 | 13.0 | 15.0 | 26.0 | 28.5 | M24 x 1.5 | 250 | |
| 467043 | 31.0 | 13.0 | 15.0 | 27.0 | 29.6 | M25 x 1.5 | 250 | |
| 467044 | 32.0 | 13.0 | 15.0 | 28.0 | 30.7 | M26 x 1.5 | 250 | |
| 467045 | 34.0 | 13.0 | 15.0 | 30.0 | 32.9 | M28 x 1.5 | 250 | |
| 467046 | 36.5 | 13.0 | 15.0 | 32.0 | 35.1 | M30 x 1.5 | 250 | |
| 467047 | 36.5 | 15.0 | 17.0 | 32.0 | 35.1 | M30 x 2 | 250 | |
| 467048 | 44.5 | 14.0 | 16.0 | 39.0 | 42.8 | M36 x 1.5 | 100 | |
| 467049 | 44.5 | 16.0 | 18.0 | 39.0 | 42.8 | M36 x 2 | 100 | |
| 467050 | 51.0 | 16.0 | 18.5 | 45.0 | 49.4 | M42 x 2 | 100 | |
| 467051 | 54.5 | 14.0 | 16.5 | 48.0 | 52.6 | M42 x 1.5 | 100 | |
| 467052 | 54.5 | 16.0 | 18.5 | 48.0 | 52.6 | M45 x 2 | 100 | |
| 467053 | 62.0 | 16.0 | 18.5 | 55.0 | 60.3 | M52 x 2 | 100 |
UNF 螺纹塑料密封盖
| 零件编号 | D (mm) | h (mm) | H (mm) | SW1 (mm) | SW2 (mm) | 配用螺纹尺寸 | 标准包装数量 | 技术制图 | |
| 467054 | 10.0 | 11.5 | 13.5 | 8.0 | 8.8 | 1/4inch x 28 | 500 | | |
| 467055 | 13.0 | 12.5 | 14.5 | 11.0 | 12.1 | 3/8inch x 24 | 500 | | |
| 467056 | 15.5 | 12.5 | 14.5 | 13.0 | 14.3 | 7/16inch x 24 | 500 | | |
| 467057 | 15.5 | 13.0 | 15.0 | 13.0 | 14.3 | 7/16inch x 20 | 500 | | |
| 467058 | 17.5 | 13.0 | 15.0 | 15.0 | 16.5 | 1/4inch x 28 | 500 | | |
| 467059 | 18.5 | 13.5 | 15.5 | 16.0 | 17.5 | 9/16inch x 18 | 500 | | |
| 467060 | 21.0 | 13.5 | 15.5 | 18.0 | 19.7 | 5/8inch x 18 | 500 | | |
| 467061 | 24.0 | 14.5 | 16.5 | 21.0 | 23.0 | 3/4inch x 16 | 500 | | |
| 467062 | 26.5 | 14.5 | 16.5 | 23.0 | 25.2 | 13/16inch x 16 | 500 | | |
| 467063 | 27.5 | 13.5 | 15.5 | 24.0 | 26.3 | 7/8inch x 18 | 500 | | |
| 467064 | 27.5 | 15.5 | 17.5 | 24.0 | 26.3 | 7/8inch x 14 | 250 | | |
| 467065 | 31.0 | 15.5 | 17.5 | 27.0 | 29.6 | 1inch x 14 | 250 | | |
| 467066 | 34.5 | 16.5 | 18.5 | 30.0 | 32.9 | 11/16inch x 12 | 250 | | |
| 467067 | 36.5 | 16.5 | 18.5 | 32.0 | 35.1 | 13/16inch x 12 | 250 | | |
| 467068 | 41.0 | 16.5 | 18.5 | 36.0 | 39.5 | 15/16inch x 12 | 250 | | |
| 467069 | 43.0 | 16.5 | 18.5 | 38.0 | 41.7 | 13/8inch x 12 | 250 | | |
| 467070 | 45.5 | 16.5 | 18.5 | 40.0 | 43.9 | 17/16inch x 12 | 250 | | |
| 467071 | 51.0 | 16.5 | 19.0 | 45.0 | 49.4 | 15/8inch x 12 | 100 | | |
| 467072 | 54.5 | 14.5 | 17.0 | 48.0 | 52.6 | 13/4inch x 16 | 100 | | |
| 467073 | 59.0 | 16.5 | 19.0 | 52.0 | 57.0 | 17/8inch x 12 | 100 | |
BSP英制管螺纹塑料密封盖
| 零件编号 | D (mm) | h (mm) | H (mm) | SW1 (mm) | SW2 (mm) | 配用螺纹尺寸 | 标准包装数量 | 技术制图 | |
| 467074 | 14.0 | 11.0 | 13.0 | 12.0 | 13.2 | 1/8inch x 28 | 500 | | |
| 467075 | 17.5 | 13.0 | 15.0 | 15.0 | 16.5 | 1/4inch x 19 | 500 | | |
| 467076 | 22.0 | 13.0 | 15.0 | 19.0 | 20.8 | 3/8inch x 19 | 500 | | |
| 467077 | 25.0 | 15.0 | 17.0 | 22.0 | 24.1 | 1/2inch x 14 | 500 | | |
| 467078 | 29.0 | 15.0 | 17.0 | 25.0 | 27.4 | 5/8inch x 14 | 500 | | |
| 467079 | 32.0 | 15.0 | 17.0 | 28.0 | 30.7 | 3/4inch x 14 | 250 | | |
| 467080 | 36.0 | 15.0 | 17.0 | 32.0 | 35.1 | 7/8inch x 14 | 250 | | |
| 467081 | 41.0 | 17.0 | 19.0 | 36.0 | 39.5 | 1inch x 11 | 250 | | |
| 467082 | 51.0 | 17.0 | 19.0 | 45.0 | 49.4 | 11/4inch x 11 | 250 | | |
| 467083 | 56.0 | 17.0 | 19.5 | 50.0 | 54.8 | 11/2inch x 11 | 100 | | |
| 467084 | 71.0 | 17.0 | 19.5 | 63.0 | 69.1 | 2inch x 11 | 100 | | |
| 467085 | 80.0 | 17.0 | 19.5 | 70.0 | 76.8 | 21/4inch x 11 | 100 | | |
| 467086 | 90.0 | 17.0 | 19.5 | 80.0 | 87.7 | 21/2inch x 11 | 100 | |
