SPDIF/TosLink 光纤数字音频分配器1X3 外贸热销

SPDIF/TosLink   数字音频1x3分配器 外贸热销

这款SPDIF/TosLink数字音频分配器可以很容易地将一路光纤信号分配到三台光纤输入设备上。

本公司所生产的设备为以下应用提供解决方案：如对噪声、传输距离及安全有限制的场所、数据中心控制、信息分配、会议室演示以及教学环境和公司培训场所。

SPDIF/TosLink   数字音频1x3分配器 外贸热销

支持音频格式……………………………………………………LPCM2.0/DTS/Dolby-AC3

峰值波长………………………………………………………………………………650nm

最大传输速率…………………………………………………………………………16Mbps

输出线缆长度…………………………………………≤40m，使用线损小于0.2dB/m线览

最大工作电流…………………………………………………………………………100mA

电源适配器规格……………交流输入 (50HZ, 60HZ) 100V-240V; 直流输出5V/500mA

工作温度范围…………………………………………………………………(0 to +40℃)

工作湿度范围………………………………………………………5 to 90%RH (无冷凝)

尺寸(长*宽*高)……………………………………………………………54x154x23.5(mm)

重量………………………………………………………………………………………35g

SPDIF/TosLink   数字音频1x3分配器

SPDIF/TosLink   数字音频1x3分配器 外贸热销

l一路光纤信号输入分配到三路光纤信号输出

l支持音频格式LPCM2.0/DTS/DOLBY-AC3

l支持信号时序重整

l使用线损小于0.2dB/m线览，输出距离可达40m

l过电压保护功能，防止接错电源适配器造成机器损坏。

l无信号损失

l安装简单

l外置5V/500mA电源适配器

SPDIF/TosLink   数字音频1x3分配器

SPDIF/TosLink   数字音频1x3分配器 外贸热销

1. Support maxium 192KHz sample rates.

2. Used optical fiber cable loss less the 0.2Db/m, Output distance is up to 30m.
3. Easy to install and use
SPDIF/TosLink   数字音频1x3分配器

连接与操作:

1. 1.  通过光纤线，将光纤信号源（如蓝光播放机、电脑等）连接到到分配器的输入端。
2. 2.  将分配器的信号输出端，通过光纤线与光纤输入设备相连（如功放机、家庭影院等）。
3. 3.  将5V电源接到分配器的DC输入接口。

Best price TosLink Splitter 1 in 3 out/ TosLink switch

• Brand Name: HDMI Extender
• Model Number: HSV691
• Place of Origin: Guangdong, China (Mainland)
• Item: TosLink splitter
• Standard Power Input: DC5V
• Audio Input: TosLink *1
• Audio Output: TosLink * 3
• Format Supported: Dolby Digital EX /Dolby Pro Logic II / Dolby Digital DTS-ES /
• SNR: 120db
• THD: 0.1%
• Channel Seperation: 120db
• ESD Protection: ±8kV (air-gap discharge) ±4kV (contact discharge)
• keywords: TosLink splitter

Packaging Details:Delivery Detail:

TosLink splitter
1. OEM accepted
2. High quality
3. Cheap price

The digital audio (S/PDIF) Toslink splitters 1x3 can let the user to connect and distribute one digital optical (S/PDIF) Toslink source to two amplifiers.

.

1. Over-voltage protection can prevent the damage caused by connecting unmatched
power adapter to the machine.
2. Used optical fiber cable loss less the 0.2dB/m, Output distance is up to 40m.
3. Support IR remote control.

1.One way of optical fiber signals splitter to three sets of SPDIF/TosLink signal receiving device.

2.Audio format support : LPCM2.0/DTS/Dolby-AC3

3.Support signal retiming

4.Used optical fiber cable loss less the 0.2Db/m, Output distance is up to 40m.

5.The input control can through R/M and also can directly press the button

6.Support last time working state memory when power off

7.Over-voltage protection can prevent the damage caused by connecting unmatched power adapter to the machine

8.LED status indication

9.No loss of quality

10.Installs in minutes

Support audio format…………………………………………………..LPCM2.0/DTS/Dolby-AC3

Peak wavelength………………........................................................................………650nm

Max baud rate…..…………….…...………………………………………………………16Mbps

Output cable distance .....……. …≤40m(Use the optical fiber cable loss less the 0.2Db/m )

Max working current………………………………………………………..……………...100mA

Power adapter format………….Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/500mA

Operating Temperature range……..…………….………………………………… (0 to +40°C)

Operating Humidity range…………….………….….……….5 to 90%RH (No Condensation)

Dimension (L x W x H)……………………………………………54x54x23.5 (mm)

 HotSpot focuses on providing creative and innovative high speed data, video, audio transfer and convert devices. Our products are well received by customers in Europe, the US, Asia, the Middle East, Africa and Australia, building a good reputation and making great market share.

With our industry leading kernel R&D team, Hotspot keep invest on new product developing and provide top level one-stop ODM/OEM service for our customers.

We are not only providing products, we also providing ODM/OEM service and solutions.  Your new ideas and requirements are welcomed.

HSV381 HDMI Matrix 4in2out

--- Shippment of   HSV381 HDMI Matrix 4in2out

      1. Item(s) will be shipped out normally within 1 working day and no later than 2 business days after the payment is received. Tracking number is provided.

      2. Payment term can be DHL,EMS,FEDEX,UPS.etc/ 3G SDI to VGA / upscaler

 ---Package contents of  HSV381 HDMI Matrix 4in2out

Matrix *1
IR Remote *1
Power Adaptor *1
Manual *1

---Warranty of  HSV381 HDMI Matrix 4in2out

       We offer 12 months guanteen. During the guarantee period,you can send back the damanged goods and we will send you good one with your next order. But this does not cover human damage or misuse of product.
