产品特点： 1. 能支持4核酷睿2 CPU 2. 内存最高支持8G
System
| ||
CPU
|
| LGA775 socket supports Intel Core?2 Quad
|
FSB
|
| 1333 / 1066 / 800 MHz
|
BIOS
|
| AMI 16Mb SPI BIOS
|
System Chipset
|
| Intel Q35 GMCH / ICH9DO
|
I/O Chip
|
| Winbond W83627DHG-A
|
System Memory
|
| Four 240-pin DIMM sockets support up to 8 GB
|
Watchdog Timer
|
| Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
|
H/W Status Monitor
|
| Monitoring temperatures, voltages, and cooling fan status. Auto throttling control when CPU overheats
|
Expansion
|
| One PCI Express X16, one PCI Express X 1,
|
S3/S4
|
| Yes
|
TPM
|
| TPM1.2 (Infineon TPM chip 9635 TT 1.2 on board)
|
Wake up Mode
|
| LAN mode (PME / RPL)
|
SmartFan Control
|
| Support 3 modes (Slient/Optimal/Performannce)
|
I/O
| ||
MIO
|
| 1 x EIDE 66/100/133, 6 x SATA II, 1 x LPT, 1 x FDD, 4 x RS-232 (5V/12V output) , 1x K/B, 1 x Mouse
|
USB
|
| 12 x USB 2.0
|
e-SATA
|
| 16 bit DIO (8-in/8-out by PCA9555)
|
Display
| ||
Chipset
|
| Intel Q35 GMCH integrated Graphics Media
|
Display Memory
|
| Intel DVMT 4.0 supports up to 284MB video memory
|
Max. 3D Resolution
|
| 2048 x 1536 @ 32 bpp (75Hz)
|
VGA
|
| on board GMA 3100
|
HDMI
|
| Through ADD2 HDMI Card
|
LVDS
|
| Through ADD2 LVDS Card
|
DVI
|
| Through ADD2 DVI Card
|
Secondary VGA
|
| Through ADD2 VGA Card
|
Audio
| ||
Audio Codec
|
| Realtek ALC888 w/o Multiple streaming or
|
Audio Interface
|
| Mic in, Line in, CD Audio in, Line out
|
Audio Amplifer
|
| Dual 6W AMP (TPA3005D2, Optional)
|
Ethernet
| ||
LAN 1
|
| Realtek RTL8111C PCI-E Gigabit Ethernet Controller
|
LAN 2
|
| Realtek RTL8111C PCI-E Gigabit Ethernet Controller
|
BackPanel I/O Port
| ||
Back Panel I/O Port
|
| 1 x PS/2 Keyboard / 1 x PS/2 Mouse / 1 x VGA port/ 1 x Parallel port / 1 x COM Port / 2 x RJ45 port/ 4 x USB 2.0/1.1 / Audio Jack (3 ports)
|
Internal I/O Connector
| ||
Internal I/O Connector
|
| * 4 x USB connectors support additional 8 USB ports (with 5V dual)
|
Mechanical & Environmental
| ||
Power Type
|
| ATX
|
Operating Temperature
|
| 0~60?XC (32~140?XF)
|
Operating Humidity
|
| 0%~90% relative humidity, non-condensing
|
Size (L x W)
|
| 12" x 9.6"(305 mm x 244 mm)
|
Weight
|
| 1.32 lbs (0.6 Kg)
|
产品图片：
