NVP6324

AHD HD/FHD Video TX

1M/2M CMOS AHD TX

Resolution up to 1080@25/30fps

FHD-over-Coax Transmission Technology

NVP6021 is a FHD-grade AHD TX chip which can be used for

perse camera applications with 720p/1080p output.

It supports YCBCr 4:2:2 input and  AHD1.0/2.0 analog output.

联系人：李小姐  联系电话：13363613550  QQ：2850206852

high quality video DAC

4X oversampling for HD/2X oversampling for FHD
Multi-format video input support
HD(720p@30/25):Non-standard
HD(720p@60/50):BT1543,BT,1847,SMPTS 296M
Multi-format vido output support
Composite(AHD1.0/AHD2.0)
On-Chip test pattern generation
Color space features
Luminace and chrominance filter response
Subcarrier frequency(fsc)and phase
Compact package and low power consumption
Operating Vltage                       3.3V/1.2V
Power Consumption                 135mW(Typical)
Package                                     40e-QFN(5mmX5mm)
Temperature Range                   0-70℃
