Hardware

Main Chipset

Realtek RTL8188CUS

Host interface

USB2.0, type A connector

LED

Link/ Activity

RF

Antennas

Built-in wire antenna (Peak Gain: -2dBi)

Operation Frequency

2412~2483.5 MHz

Typical Transmit Power

(Onboard-Without

antenna)

802.11b (CCK) 11Mbps: 18+/-1dBm

Receive Sensitivity

(Onboard-Without

antenna)

802.11b: -86+/-1dBm @ 11Mbps

Software

Operation System

Windows XP,Vista,Win7 ;Mac OS X and Linux

Security

WEP , WPA, WPA2, WAPI, QoS (802.11e and WMM),

Operation Conditions

Voltage Range

DC 5.0 V ± 5%

Current Range

140+/-5mA @ 802.11g, 54Mbps; 185+/-5mA @802.11b , 11Mbps

Operating Temperature

-10°C - 60°C

Storage Temperature

-20°C - 80°C

Operating Humidity

RH 95% (Non-Condensing)

Storage Humidity

RH 95% (Non-Condensing)

Physical Specification

Dimensions

32.5x14.2x7.2mm

Weight

3.6g
