Operation System

CPU Supplier

Driver

Linux 2.4/2.6

ARM, MIPSII

Available

Windows 2000/XP/Vista/7

X86 Platform

Available

Mac OS X 10.3/10.4/10.5/10.6

N/A

Available

Agency

Approval

FCC Part15

Ready to test

CE

Ready to test

RoHS

Yes

Hardware

Main Chipset

Ralink RT5370

Host interface

USB 2.0/1.1 Type A

LED

Link/ Activity

RF Performance

Standards

IEEE802.11b/g & 802.11n (1T1R mode, 150Mbps)

Antenna

2dBi undetachable antenna

Operation Frequency

2412~2483.5 MHz (varies according to different regions).

Typical Tx Power (E.R.I.P)

802.11b (CCK)11Mbps: 19+/-1dBm; 802.11g (OFDM) 54Mbps: 16+/-1dBm

Receive Sensitivity

802.11b: -86+/-1dBm; 802.11g: -74+/-1dBm

Software Support

Operation System

WindowsCE/2000/XP/Vista/7; Linux 2.6.X; Mac OS X

Security

WEP 64/128bit , WPA, WPA2, 802.1x, and 802.11i,Cisco CCS Compliant

Operation conditions

Voltage Range/Current

DC 5.0V ± 5% / <160mA

Temperature

Operation: -10°C - 60°C;   Storage:-20°C - 70°C

Humidity(Non-Condensing)

Operation: RH 95%;     Storage : RH 95%

Physical Specification

Dimensions

(Main body)16.4x14.7x58mm, details refer to the figures.

Net Weight

9.8 g
