Product Data Sheet
Eastar™ Copolyester AN001, Natural
|
Application/Uses | - Cosmetics/personal care packaging
- Fragrance packaging
|
| Key Attributes | - Easy to extrude, cut, print, and seal
- Effective barrier properties
- Excellent chemical resistance
- Excellent clarity
- Excellent colorability
- Good impact strength
- Good stiffness
- High gloss appearance
- Toughness
|
|
|
Product Description |
Eastar™ AN001 Copolyester has excellent appearance and is nearly water-clear. Its most outstanding features are its chemical resistance and processing capabilities. Exposure to aromatic oils often causes crazing or actual fracture of many polymer resins, but AN001 maintains its physical properties when exposed to these oils, and its appearance is virtually unchanged. This product has been GREENGUARD INDOOR AIR QUALITY CERTIFIED®. The GREENGUARD INDOOR AIR QUALITY CERTIFIED® Mark is a registered certification mark used under license through the GREENGUARD Environmental Institute (GEI). GEI is an industry-independent, non-profit organization that oversees the GREENGUARD Certification Program. The GREENGUARD Certification Program is an industry independent, third-party testing program for low-emitting products and materials for indoor environments. For more information about GEI and to obtain printable certificates for Eastman™ Copolyesters, visitwww.greenguard.org. Choose Eastman Chemical Company under the Manufacturer category and click search to display a list of our products. This product has been CRADLE TO CRADLE CERTIFIEDcm The CRADLE TO CRADLE CERTIFIEDcm Mark is a registered certification mark used under license through McDonough Braungart Design Chemistry (MBDC). MBDC is a global sustainability consulting and product certification firm. The CRADLE TO CRADLE® framework moves beyond the traditional goal of reducing the negative impacts of commerce (‘eco-efficiency’), to a new paradigm of increasing its positive impacts (‘eco-effectiveness’). At its core, Cradle to Cradle design perceives the safe and productive processes of nature’s ‘biological metabolism’ as a model for developing a ‘technical metabolism’ flow of industrial materials. Product components can be designed for continuous recovery and reutilization as biological and technical nutrients within these metabolisms. For more information about MBDC and to obtain printable certificates for Eastman Copolyesters, visit |
|
Typical Properties |
|
|
Propertya | Testb Method | Typical Value, Unitsc |
Specific Gravity | D 792 | 1.20 |
Mold Shrinkage Parallel to Flow, 3.2-mm (0.125-in.) thickness | D 955 | 0.002-0.006 mm/mm (0.002-0.006 in./in.) |
|
Mechanical Properties |
Tensile Stress @ Yield | D 638 | 47 MPa (6900 psi) |
Tensile Stress @ Break | D 638 | 51 MPa (7400 psi) |
Elongation @ Yield | D 638 | 5% |
Elongation @ Break | D 638 | 320% |
Flexural Modulus | D 790 | 2000 MPa (2.9 x 105 psi ) |
Flexural Yield Strength | D 790 | 69 MPa (10000 psi) |
Rockwell Hardness, R Scale | D 785 | 103 |
Izod Impact Strength, Notched |
| D 256 | 80 J/m (1.5 ft·lbf/in.) |
| D 256 | 40 J/m (0.7 ft·lbf/in.) |
Impact Strength, Unnotched |
| D 4812 | NB |
| D 4812 | NB |
Impact Resistance (Puncture), Energy @ Max. Load |
| D 3763 | 42 J (31 ft·lbf) |
| D 3763 | 48 J (35 ft·lbf) |
|
Thermal Properties |
Deflection Temperature |
| D 648 | 73°C (164°F) |
| D 648 | 65°C (149°F) |
|
Optical Properties |
Haze | D 1003 | 0.3% |
Regular Transmittance | D 1003 | 89% |
Total Transmittance | D 1003 | 91% |
|
Typical Processing Conditions |
Drying Temperature | | 70°C (160°F) |
Drying Time | | 3 hrs |
Processing Melt Temperature | | 230-280°C (450-530°F) |
Mold Temperature | | 15-30°C (60-80°F) |
