2104N4214 Excel cross-duct gas detection system, short range (0.5 to 2.5m), 4 to 20mA (source) and Modbus outputs, ATEX/IECEx, fully wired with flexible conduit, electro polished 316SS. Includes detection block, single tile heated reflector panel, Ex e junciton box with M20/M25 cable entries and 316SS mounting plate. Methane calibration only
2104N1010 Excel cross-duct gas detection system, short range (0.5 to 2.5m), 4 to 20mA (source) and Modbus outputs, UL, fully wired with flexible conduit, electro polished 316SS. Includes detection block, single tile heated reflector panel and 316SS mounting plate. Methane calibration only.
Note Duct Mounting Kit [2440K0004] must be ordered seperately
2104N4224 Excel cross-duct gas detection system, long range (2.5 to 5.0m), 4 to 20mA (source) and Modbus outputs, ATEX/IECEx, fully wired with flexible conduit, electro polished 316SS. Includes detection block, quad tile heated reflector panel, Ex e junciton box with M20/M25 cable entries and 316SS mounting plate. Methane calibration only
2440K0004 | Duct mounting kit for use with UL approved short range cross duct systems. Comprises DX100M, junction box and flexible conduit. |
2441-0027 | 8 terminal junction box for remote mounted cross duct systems ( 3 x 3/4"NPT entries) |
00780-A-0100 | Honeywell Junction Box- Bartec OTB122 With Continuity Plate 1 x 25mm - 3 x 20mm Entries - ATEX Approved |
2104B0715 | Heated Reflector Panel for Short Range ATEX |
2104B0717 | Heated Reflector Panel for Short Range UL Certified |
2104B0716 | Heated Reflector Panel for Long Range ATEX |
2104D2537 | Retro-reflector mounting plate for Long Range |
2104D2536 | Retro-reflector mounting plate for Short Range |
2104D2505 | Mounting plate, Cross-Duct, Stainless Steel |
2104D2506 | Support strap, Cross-Duct mounting plate |
2104D2542 | Support strap, Cross-Duct retro-reflector for Long Range |
2104D2541 | Support strap, Cross-Duct retro-reflector for Short Range |
04230-A-1001 | Hand Held Interrogator ATEX Certified (4V0 software) for Optima, Optima Plus and Searchline Excel |
2104B2351 | Hand Held Interrogator UL Certified (4V0 software) for Optima, Optima Plus and Searchline Excel |
2108B1455 | Hand Held EEPROM upgrade (4V0) |
04230-A-1025 | SHC protection device module and lead |
2104B6250 | SHC Calibrator Connector System 10m |
157-001-100 | Termination Unit, Black GRP, Ex e, 1 x M25 and 4 x M20 cable entries, 12-way terminal strip, 2 x earth terminals. Includes 4 way links, 4 x M20, and 1 x M25 stopping plugs |
2104B2382 | DX100M XP Termination Unit UL with Modbus capability |
2104N3000 | Excel Cross-Duct test filters kit and manual |
2108D0271 | Remote gassing pipe
|
