【霍尼韦尔 FS24X 火焰探测器 FS24X-211-21-1】价格_厂家

霍尼韦尔 FS24X 火焰探测器 FS24X-211-21-1

不限

￥2200

中国深圳

产品属性

图文详情

品牌推荐

品牌

Honeywell/霍尼韦尔

型号

FS24X-211-21-1

类型

可燃性气体检测仪

安装方式

固定式

测量范围

2 x M20 entries,

测量对象

ATEX/IECEx

测量精度

1 x M25 entry

分辨率

painted LM25

电源

工作温度范围

-60-85℃

工作湿度范围

0-100%

壳体材料

316ss

防护等级

IP66

防爆等级

IP67

加工定制

否

外形尺寸

300*150*200㎜

重量

3㎏

电气接口

M25

连接方式

3/4NPT

驱动软件

带光盘

是否标定气体

是

是否带检测证书

是

FS24X-211-21-1	QuadBand™ IR3+ Detector, Copper-Free Aluminum Encl., (2) ¾" NPT entries FM, cFM, IECEx & ATEX approved
FS24X-211-22-1	QuadBand™ IR3+ Detector, 316 Stainless Steel Encl., (2) ¾" NPT entries FM, cFM, IECEx & ATEX approved
FS24X-211-23-1	QuadBand™ IR3+ Detector, Copper-Free Aluminum Encl., (2) M25 entries FM, cFM, IECEx & ATEX approved
FS24X-211-24-1	QuadBand™ IR3+ Detector, 316 Stainless Steel Encl. (2) M25 entries FM, cFM, IECEx & ATEX approved

FS24X-911-21-1	QuadBand™ IR3+ Detector, Copper-Free Aluminum Encl., (2) ¾" NPT entries FM, cFM, IECEx & ATEX approved
FS24X-911-22-1	QuadBand™ IR3+ Detector, 316 Stainless Steel Encl., (2) ¾" NPT entries FM, cFM, IECEx & ATEX approved
FS24X-911-23-1	QuadBand™ IR3+ Detector, Copper-Free Aluminum Encl., (2) M25 entries FM, cFM, IECEx & ATEX approved
FS24X-911-24-1	QuadBand™ IR3+ Detector, 316 Stainless Steel Encl. (2) M25 entries FM, cFM, IECEx & ATEX approved
FS24X-911-21-6	QuadBand™ IR3+ Detector, Copper-Free Aluminum Encl., (2) ¾" NPT entries FM, cFM, IECEx, ATEX and EN54-10 approved
FS24X-911-22-6	QuadBand™ IR3+ Detector, 316 Stainless Steel Encl., (2) ¾" NPT entries FM, cFM, IECEx, ATEX and EN54-10 approved
FS24X-911-23-6	QuadBand™ IR3+ Detector, Copper-Free Aluminum Encl., (2) M25 entries FM, cFM, IECEx, ATEX and EN54-10 approved
FS24X-911-24-6	QuadBand™ IR3+ Detector, 316 Stainless Steel Encl. (2) M25 entries FM, cFM, IECEx, ATEX and EN54-10 approved

FS24X-212-22-1	FS24X-211-22-1 QuadBand™ IR3+ Detector, 316 Stainless Steel Encl.,
	(2) ¾” NPT entries FM, cFM, IECEx & ATEX approved with FSX-A014R
	Optional Registered HART® Module for FS24X Detectors Factory installed
FS24X-212-23-1	FS24X-211-23-1 QuadBand™ IR3+ Detector, Copper-Free Aluminum Encl.,
	(2) M25 entries FM, cFM, IECEx & ATEX approved with FSX-A014R
	Optional Registered HART® Module for FS24X Detectors Factory installed
FS24X-212-24-1	FS24X-211-24-1 QuadBand™ IR3+ Detector, 316 Stainless Steel Encl. (2) M25
	entries FM, cFM, IECEx & ATEX approved with FSX-A014R
	Optional Registered HART® Module for FS24X Detectors Factory installed

FS24X-912-21-1	FS24X-911-21-1 QuadBand™ IR3+ Detector, Copper-Free Aluminum Encl.,
	(2) ¾”NPT entries FM, cFM, IECEx & ATEX approved with FSX-A014R
	Optional Registered HART® Module for FS24X Detectors Factory installed
FS24X-912-22-1	FS24X-911-22-1 QuadBand™ IR3+ Detector, 316 Stainless Steel Encl.,
	(2) ¾” NPT entries FM, cFM, IECEx & ATEX approved with FSX-A014R
	Optional Registered HART® Module for FS24X Detectors Factory installed
FS24X-912-23-1	FS24X-911-23-1 QuadBand™ IR3+ Detector, Copper-Free Aluminum Encl., (2)
	M25 entries FM, cFM, IECEx & ATEX approved with FSX-A014R
	Optional Registered HART® Module for FS24X Detectors Factory installed
FS24X-912-24-1	FS24X-911-24-1 QuadBand™ IR3+ Detector, 316 Stainless Steel Encl. (2) M25
	entries FM, cFM, IECEx & ATEX approved with FSX-A014R Optional Registered
	HART® Module for FS24X Detectors Factory installed

SM4	Stainless Steel Swivel mounting assembly for FS24X, FS20X, SS4, SS2 detectors
PSU-12	Universal charger for Fire Sentry Test Lamps and Interface Kits. For 110-240 VAC with international plugs
TL-2055	IR Test lamp for testing FSX detectors, explosion proof version. Incl universal charger
TL-1055	IR Test lamp for testing FSX detectors, non-explosion proof version. Incl universal charger
SH-001	Sunshield for SS2, SS4, FS20X and FS24X Detectors, 316 Stainless Steel
FSX-A001	FSX and FS220 Interface Kit with Interface Module, RS485 Cable, USB Cable, Power Adapter and Windows PC Software
FSX-A002	FSX Interface Module with RS485 Cable
FSX-A014R	Optional Registered HART® Module for FS24X Detectors

FS24X-211-10	Replacement Electronics Module for 211 Series standard temperature range detector
FS24X-911-10	Replacement Electronics Module for 911 Series standard temperature range detector
FS24X-911-10-6	Replacement Electronics Module for 911 (90° FoV)Series standard temperature range detector. EN54-10.
FS24X-212-10	110° FoV Electronics Module with Registered HART® Communication
FS24X-912-10	90° FoV Electronics Module with Registered HART® Communication
FSX-A006	Replacement IR Bulb for TL1055 and TL2055

FS20X-211-21-2	DUAL IR/UV FLAME DETECTOR Copper-Free Aluminum Encl. with (2) ¾” NPT
	entries, FM, cFM for Class I, Division 1, Groups A, B, C, D; Class II, Division 1,
	Groups E, F, G; Class III
FS20X-211-22-2	DUAL IR/UV FLAME DETECTOR Stainless Steel Encl. with (2) ¾”NPT entries,
	FM, cFM for Class I, Division 1, Groups A, B, C, D; Class II, Division 1, Groups E,
	F, G; Class III
FS20X-211-23-3	DUAL IR/UV FLAME DETECTOR Copper-Free Aluminum Encl. with (2) M25
	entries, FM, cFM, ATEX, IECEx for Class I, Zone 1
FS20X-211-24-3	DUAL IR/UV FLAME DETECTOR Stainless Steel Encl. with (2) M25 entries, FM,
	cFM, ATEX, IECEx for Class I, Zone 1
FS20X-211-21-6	DUAL IR/UV FLAME DETECTOR Copper-Free Aluminum Encl. with (2) ¾” NPT entries, FM, cFM for Class I, Division 1, Groups A, B, C, D; Class II, Division 1, Groups E, F, G; Class III. With En54-10 certification
FS20X-211-22-6	DUAL IR/UV FLAME DETECTOR Stainless Steel Encl. with (2) ¾”NPT entries, FM, cFM for Class I, Division 1, Groups A, B, C, D; Class II, Division 1, Groups E, F, G; Class III. With En54-10 certification
FS20X-211-23-6	DUAL IR/UV FLAME DETECTOR Copper-Free Aluminum Encl. with (2) M25 entries, FM, cFM, ATEX, IECEx for Class I, Zone 1. With En54-10 certification
FS20X-211-24-6	DUAL IR/UV FLAME DETECTOR Stainless Steel Encl. with (2) M25 entries, FM, cFM, ATEX, IECEx for Class I, Zone 1. With En54-10 certification

FS20X-212-21-2	FS20X-211-21-2 DUAL IR/UV FLAME DETECTOR Copper-Free Aluminum Encl.
	with (2) ¾” NPT entries, FM, cFM for Class I, Division 1, Groups A, B, C, D; Class
	II, Division 1, Groups E, F, G; Class III with FSX-A014 Optional HART® Module
	for FS20X Detectors Factory installed
FS20X-212-22-2	FS20X-211-22-2 DUAL IR/UV FLAME DETECTOR Stainless Steel Encl. with
	(2) ¾”NPT entries, FM, cFM for Class I, Division 1, Groups A, B, C, D; Class II,
	Division 1, Groups E, F, G; Class III with FSX-A014 Optional HART® Module for
	FS20X Detectors Factory installed
FS20X-212-23-3	FS20X-211-23-3 DUAL IR/UV FLAME DETECTOR Copper-Free Aluminum Encl.
	with (2) M25 entries, FM, cFM, ATEX, IECEx for Class I, Zone 1 with FSX-A014
	Optional HART® Module for FS20X Detectors Factory installed
FS20X-212-24-3	FS20X-211-24-3 DUAL IR/UV FLAME DETECTOR Stainless Steel Encl. with (2)
	M25 entries, FM, cFM, ATEX, IECEx for Class I, Zone 1 with FSX-A014 Optional
	HART® Module for FS20X Detectors Factory installed

FSX-A014	Optional HART® Module for FS20X Detectors
SM4	Stainless Steel Swivel mounting assembly for FS24X, FS20X, SS4, SS2 detectors
PSU-12	Universal charger for Fire Sentry Test Lamps and Interface Kits. For 110-240 VAC with international plugs
TL-2055	IR Test lamp for testing FSX detectors, explosion proof version. Incl universal charger
TL-1055	IR Test lamp for testing FSX detectors, non-explosion proof version. Incl universal charger
SH-001	Sunshield for SS2, SS4 & FS24X Detectors, 316 Stainless Steel
FSX-A001	FSX Interface Kit with Interface Module, RS485 Cable, USB Cable, Power Adapter and Windows PC Software
FSX-A002	FSX Interface Module with RS485 Cable

FS20X-211-10	Replacement Electronics Module for FS20X Detectors. Module only, Standard Temp. Range
FS20X-211-10-6	Replacement Electronics Module for FS20X Detectors. Module only, Standard Temp. Range. EN54-10.
FS20X-212-10	Electronics Module with HART® Communication
FSX-A006	Replacement IR Bulb for TL1055 and TL2055

DASA1-P	Airshield to prevent dust build up with fitting for 1/4" tubing. SS4, FS20X, FS24X
DASA6-N	Airshield to prevent dust build up with fitting for 6mm tubing. SS4, FS20X, FS24X
94000-C-1001	Universal 2” pipe Mounting Plate. For Fire Sentry SS4, FS20X and FS24X (use 90083-A-8034 Kit)
90083-A-8034	2 x 2" U-Bolts x M6 C/W Nuts and Washers 316SST
FVR-01	Field of View Restrictor
RDU300504	Reducer, ATEX, Ex d e, 316SS, M25 (male) to M20 (female)
RDU303029	Reducer, ATEX, Ex d e, 316SS, 3/4"NPT (male) to 1/2"NPT (female)
RDU303004	Reducer, ATEX, Ex d e, 316SS, 3/4"NPT (male) to M20 (female)
RDU300530	Reducer, ATEX, Ex d e, 316SS, M25 (male) to 3/4"NPT (female)
RDU300529	Reducer, ATEX, Ex d e, 316SS, M25 (male) to 1/2"NPT (female)

2108B2001N	Hydrocarbon Searchpoint Optima Plus, ATEX
2108B2001H	Hydrocarbon Searchpoint Optima Plus HART®, ATEX
2108B2003N	Ethylene Searchpoint Optima Plus, ATEX
2108B2003H	Ethylene Searchpoint Optima Plus HART®, ATEX
2108B2101N	Hydrocarbon Searchpoint Optima Plus, UL/Inmetro
2108B2101H	Hydrocarbon Searchpoint Optima Plus HART®, UL/Inmetro
2108B2103N	Ethylene Searchpoint Optima Plus, UL/Inmetro
2108B2103H	Ethylene Searchpoint Optima Plus HART®, UL/Inmetro
2108B2201N	Hydrocarbon Searchpoint Optima Plus, FM/CSA
2108B2201H	Hydrocarbon Searchpoint Optima Plus HART®, FM/CSA
2108B2041N	Hydrocarbon Searchpoint Optima Plus, CU-TR Ex
2108B2041H	Hydrocarbon Searchpoint Optima Plus HART®, CU-TR Ex
2108B2043N	Ethylene Searchpoint Optima Plus, CU-TR Ex
2108B2043H	Ethylene Searchpoint Optima Plus HART®, CU-TR Ex
2108B2051N	Hydrocarbon Searchpoint Optima Plus, Marine (MED)
2108B2051H	Hydrocarbon Searchpoint Optima Plus HART®, Marine (MED)
2108B2053N	Ethylene Searchpoint Optima Plus, Marine (MED)
2108B2053H	Ethylene Searchpoint Optima Plus HART®, Marine (MED)
2308B0970	HALO Lid assembly – ATEX/IECEx
2308B0974	HALO Lid assembly – with HART® connection ATEX/IECEx
2308B0978	HALO Blanking cap / magnet assembly including lanyard
2308B0924	HALO Terminal block spares assembly
2308B0969	HALO Service Spares Kit
