1、 | 产品名称/Product Name: | | | | | |
| LED恒压电源/Constant Voltage LED power supply PVA-12100G | | | |
2、 | 产品输入规格/Product Input Specifications | | | | |
| 输 入 电 压 Input Voltage | 输 入 频 率 Input Frequency | 输 入 电 流 Input Current | 功 率 因 数 Power Factor | 浪 涌 110V Inrush Current | 浪 涌 230V Inrush Current | 谐波总量 Total Syntonic Wave |
| 110/220V | 40-60Hz | 0.3-0.5A | 0.5-0.6 | 10A | 20A | 20%Mac |
3、 | 产品输出规格/Product Output Specifications | | | | |
| 输 出 电 压 Output Voltage | 输 出 最 大 功 率 Max. Output Power | 输 出 电 流 Output Current | 效 率 Efficiency | 空 载 功 率 No-load power | 输 出 纹 波 Output Ripple | 负 载 调 整 率 Load Regulation |
| 12±5% | 100W | 8.3A | 82%/220V | 2.5W | ≦150MV | ≦±10% |
4、 | 保护功能/Protection Function | | | | | |
| 过压、过流、短路保护/Over voltage,over current,short circuit protection:Auto-recovery. | |
5、 | 环境规格/Environmental Specifications | | | | |
| 操 作 温 度 Operation Temp. | 存 储 温 度 Store Temp. | 温 升 Raise Temp. | 操 作 湿 度 Operation Humidity | 环 境 保 护 Env. Protaction | 使 用 场 地 Using Field | |
| -25~50℃ | -40~80℃ | ≤28℃ | 5-95%RH | | | |
6、 | 参照标准/Reference Srandards | | | | | |
| 6.1、 安全标准/Safety Standards:GB195110.1-2004/IEC61347-1:2003 CE(EMC+LVD) certificate | |
| 6.2、 EMC标准/EMC Standard:EN55015,EN61000,EN61547 | | | |
7、 | 产品尺寸、外形/ Size & Figure | | | | | |
| 7.1、产品尺寸/Size:199*98*38MM | | | | | |
| 7.2、外壳材质/Case Material:铝合金/AL | | | | |
8、 | 包装规格/Packing Specifications | | | | | |
| 单 个 重 量 Unit Weight | 包 装 尺 寸 Packing Size | 包 装 数 量 Packing Qty. | 包 装 重 量 Packing Weight | 包 装 方 式 Packing Method | | |
| 650g/pcs | 440*280*170mm | 40pcs/Box | 24Kg/Box | 10*4Layers | | |
| | | | | | | |
9、 | 产品应用/Product Application | | | | | |
| 产品适用于LED串并结合的护栏管、投光灯、发光字、洗墙灯、路灯等 | | | |
The product designed to drive LED guardrail lamp、 flood light、 light word 、street lamp etc.For LEDs series-parallel. |
| | | 驱动1664PCS LEDS 4串416并/Drive 896pcs LEDS 4 series 416 parallels | |
