SU2 - Optics Edition
SU2-光学版
The new CNC milling and engraving machines are able to calculate thetool paths with highest accuracy and to machine them with great dynamic.
Hig accuracy and perfect surface quality can, however, only be achieved by using a machining tool with an exact grinding.
With the SU2 grinder we offer a modern quality product with a large set of accessories to meet the high requirements to versatility, precision and effectiveness for grinding, engraving and milling cutters. The integrated tool measuring system allows for exact measuring of the cutting edge during the grinding process, without taking the cutter off the grinder.
Highest concentricity and short setting-up times are ensured by our direct clamping system of the tool cones.
新型的数控铣床和雕刻机能够以最高精确度计算刀具路径，使机器加工起来有很大动力。
高精度和完美的表面质量，无论如何只能通过加工刀具的精密磨刀机来实现。
用SU2磨刀机，我们可以提供现代化的高品质产品，还带有一整套的配件来满足对磨削铣刀和雕刻机刀具多样性、精度和效率的高要求。集成刀具测量系统，在磨削过程中，可以精确测量刀具的切削刀刃，并且不用将刀具从磨刀机取下。
我们的工具锥柄直接夹持系统确保了最高同轴度和快速装夹刀具。
SU2符合最高要求并带刀具测量系统！
Technical data:技术参数 | |||||
| Dimensions / Weight 尺寸/重量 |
| mm•kg |
| 360 x 480 x 350•40 |
| Rotational speed milling spindle 主轴转速 |
| 1/min |
| 5.500 |
| Tool diameter 刀具直径 |
| mm |
| 1,0 - 18 |
| Measuring range X x Y 测量范围X x Y |
| mm |
| 14 x 22 |
| Magnification of optic 镜片放大率 |
|
|
| 20fold (40fold) 20倍（40倍） |
Design characteristics：设计特点 | |
| Sturdy machine housing with built-in, dust-protected drive motor 坚固的机器外罩以及内置防尘驱动电机。 |
| Guiding shaft with counter bearing 带轴转速计导向轴 |
| backlash-free highly precise fine adjustment; reading accuracy: 0,01 mm 无间隙高精密度微调，读数精度：0.01mm |
| Grinding spindle with precision ball bearings and dust protection 带精密球轴承和防尘保护的砂轮主轴 |
| Integrated tool measuring system MSK with precision coordinate guidance 精密坐标制导MSK集成测量系统 |
| Weight balance for compensation of weight of MSK MSK补偿砝码重量平衡 |
Options选项
'
